40×80 Conveyor Frame Profile
The 40×80 conveyor frame profile is used as a crossbeam in the support structure. Its section and connection arrangement need to match the upright supports and the required frame span.
- Designation
- 40×80
- Role
- Crossbeam
- Assembly
- Conveyor support frame
Specify the profile section and connection hardware together. The 40×80 designation alone does not determine slot geometry or structural capacity.
Connect the Uprights Across the Frame
A crossbeam ties the support structure across its span and provides attachment positions for the surrounding conveyor assembly. Its orientation determines which faces and slots are available to the connecting brackets.
The 40×80 profile should be matched from its actual section. Compare the end shape and joint details before replacing a member in an existing frame. Two profiles with the same designation can use different slot and fastening arrangements.
Specifications
| Parameter | Specification |
|---|---|
| Profile designation | Specification: 40×80 |
| Documented use | Specification: Crossbeam |
Dimensions & Fit
Provide a section drawing or clear end-view photograph. Mark the installed orientation and the distance between the supporting uprights.
Show the joint hardware and fixing locations. Assess member loading and support spacing for the frame design before finalizing the profile and cut length.
Form the Transverse Support Structure
A crossbeam links the conveyor supports and helps establish their relative positions. Equipment loads reach it through the attached brackets, so the joint positions influence the load path as well as the usable mounting space.
Check access beneath the conveyor when laying out the frame. Crossbeam placement should allow maintenance around the drive and return path without obstructing the required supports.
Discuss a 40×80 Profile
Send the 40×80 section reference, required length and quantity. Include joint photographs, frame span and intended loading for selection review.
