105 Flexible Chain Conveyor Transfer
The 105 flexible chain conveyor transfer addresses the handoff between adjoining conveying sections. Selection starts with the product base, transfer gap and the position of both conveyor ends.
- Family
- 105
- Role
- Product handoff
- Type
- Powered transfer
Confirm the actual 105 assembly before defining its drive. The family reference does not establish a motor, reducer or mounting footprint.
Maintain Support Across the Handoff
A product leaving one conveyor needs support until it reaches the next carrying surface. A powered transfer adds a moving contact region within that handoff. Its usefulness depends on how the product base crosses the gap.
For the 105 family, compare the two conveyor ends before selecting the transfer assembly. End geometry, carrying level and the available installation space determine where the moving transfer surface can sit. The drive arrangement needs to be established for the actual assembly.
Specifications
| Parameter | Specification |
|---|---|
| Product family | Specification: 105 flexible-chain transfer |
| Function | Specification: Powered product handoff between conveyor sections |
| Selection basis | Specification: Product base, transfer gap and adjoining end geometry |
Dimensions & Fit
Show both conveyor ends in plan and side elevation. Mark the carrying levels, available gap and direction of travel.
Check the product's smallest base dimension against the remaining unsupported distance. Include the available drive-side space and the required operating speed for the assembly review.
Bridge the Gap Between Carrying Surfaces
At an end-to-end transfer, a short or narrow product base can lose support before reaching the receiving conveyor. A moving transfer surface can form part of the support across that region, subject to the actual assembly geometry.
Check the approach and receiving speeds together. Relative movement at the handoff affects how the product enters the next section, especially for light or unstable packs.
Discuss a 105 Transfer
Send the 105 family reference, product-base dimensions and drawings of both conveyor ends. Include the gap, levels, operating speed and quantity.
